>Buy sur-Ron storm bee<
Surron’s First Full-Size Electric Dirt Bike
Sur-Ron Storm – Full Size Electric MX/ Enduro Bike. After years of development & innovation, Sur-Ron is now in the final development stages of the new full size electric dirt bike – the STORM. Equipped with the latest 96 volt high power system with gearbox, all new aluminum alloy forged frame, the top level 10C discharge rate lithium-ion battery. 290mm suspension travel up front. Plus a road legal version with ABS. It’s a full size dirt bike with massive power & the best power to weight ratio in its class.....
Buy sur-Ron storm bee | Best sur-Ron storm bee | sur-Ron storm bee in stock | Order sur-Ron storm bee |
KEY FEATURES OF THE 2023 STORM BEE
- Liquid-cooled, brushless electric motor
- 22.5 kW peak power, 520 Nm peak torque
- Max. range: 120 km (75 miles) on a full charge @ 50 km/h (31 mph)
- 3 riding modes, traction control, regenerative braking
- Turbo mode & reverse gear
- Adjustable off-road suspension, 21/18” wheels (front/rear)
- Quiet & emissions-free
- Switchable headlight & number plate included (North American version only) Best sur-ron storm bee!
TECHNICAL SPECIFICATIONS
POWERTRAIN
| Motor Type | Liquid-cooled, brushless electric (BLDC) motor |
| Rated Voltage | 104V (DC) |
| Rated Power/Peak Power | 10,000W/22,500W |
| Controller Type | FOC Sine Wave |
| Peak Torque | 520 Nm (383 ft-lbs) |
| Top Speed | 110 km/h (68 mph) |
| Max Range | 120 km @ 50 km/h (75 miles @ 31 mph), depending upon terrain) |
| Battery | 104V/55Ah Lithium Ion |
| Charger | 10A |
| Charging Time | 4 Hours (0-100%) |
| Drive | 530 O-ring Chain |
RIDER AIDS
| Riding Modes | Sport, Rain, Eco, Turbo |
| Rider Aids | ASR (Acceleration Slip Reduction, a.k.a. traction control), BERS (Brake Energy Regenerative System) |
| Reverse Gear | Button-activated |
CHASSIS
| Front Suspension | 47 mm inverted fork, 290 mm travel, adjustable compression & rebound |
| Rear Suspension | Fully adjustable mainshock, 290 mm wheel travel |
| Front Wheel | 21″ wire-spoked rim, 80/100-21 off-road tire |
| Rear Wheel | 18″ wire-spoked rim, 100/90-18 off-road tire |
| Curb Weight | 127 kg (280 lbs) |
| Max Load | 100 kg (220 lbs) |
| Vehicle Dimensions | 2,080 mm x 805 mm x 1,240 mm (81.9 x 31.7 x 48.8”) |
| Minimum Ground Clearance | 310 mm (12.2″) |
| Wheelbase | 1,430 mm (56.3″) |
| Seat Height | 940 mm (37″) |
ADDITIONAL FEATURES
| USB Connection | Single USB-2.1A Outlet |
| Instrumentation | LCD Digital Dash |
| Headlight | LED |
Specifications subject to change without notice. Battery ranges are estimated. Actual range may vary.
IMPRESSIVE FRAME DESIGNThe Storm Bee’s high-strength aluminum frame offers both stiffness and flexibility to optimize the riding experience. The compact arrangement of the battery pack, motor control unit (MCU) and motor minimizes unsprung weight and balances the Storm Bee. The 1,430 mm wheelbase and steering geometry give the Storm Bee great maneuverability and excellent high-speed stability off-road.
|
 |
|
|
TURBO & REVERSE BUTTONSTwo of the most unique features on the Surron Storm Bee are turbo and reverse. Pressing the turbo button gives you a short, extra boost of power at full throttle. Meanwhile, the functional reverse button will be a welcome feature for riders who find themselves in tricky situations on the trail. It’s this kind of innovation and outside-the-box thinking that sets Surron apart. |
HIGH PERFORMANCE ELECTRIC POWERTRAINThe heart of the Storm Bee’s powertrain is its 104V/55Ah battery pack, powerful enough to propel the Storm Bee to a top speed of 75 mph and a max range of 70 miles. Recharge the Storm Bee via its included charger through a conventional wall outlet in 4 hours. A precision-built FOC motor control unit safely and efficiently manages power to the liquid-cooled, brushless (BLDC) motor. Built-in sensors automatically optimize power delivery if temperatures get too high, maximizing battery life.
|
|
Product may vary from images shown.
WHAT ARE THE ASR AND BERS FUNCTIONS?
BERS (E-Brake Energy Return System)
The Storm Bee comes standard with a multi-level, adjustable energy system to regenerate the battery during braking. Enjoy extra range and enjoy the ride without the anxiety. sur-ron storm bee near me!
ASR (Active Spin Reduction)
The ASR traction control system was independently developed by Sur-Ron. With multiple levels of control and on-the-fly adjustability, the Storm Bee can adapt to a variety of road conditions for optimal grip and improved safety. Buy sur-Ron storm bee!
Tested and certified protection against dirt, dust and wet weather use under normal riding conditions. sur-Ron storm bee in stock!
SPECIFICATION
| MOTOR | |
| Motor Type: | Mid-Drive BLDC Motor |
| Mounting Position: | Mid Mounted |
| Weight / Motor External Diameter: | TBA |
| Motor Axial Length: | TBA |
| Peak Efficiency: | TBA |
| Cooling Method: | Water Cooled |
| CONTROLLER | |
| Controller Type / Weight: | FOC Sine Wave Controller |
| Dimensions: | 2120 x 805 x 1265mm (including battery) |
| Peak Efficiency: | TBA |
| Traveling Wave Current / Highest Work Temperature | TBA |
| MOTOR POWER SYSTEM | |
| Rated Voltage: | TBA |
| Rated Power / Peak Power: | 22.5KW (96V） |
| Rated Torque / Peak Torque: | 520 N.m |
| Acceleration: | Acceleration(S)：1.9(0-50KM) Acceleration(S)：3.3(0-70KM) Acceleration(S)：3.9(0-80KM) |
| Rated Load: | 120KG |
| Road Legal: | Yes |
| TRANSMISSION | |
| Gear Ratio: | TBA |
| Transmission: | Automatic |
| Belt Brand & Model: | TBA |
| ELECTRICAL COMPONENTS | |
| Speedometer: | TBA |
| Battery: |
90V48Ah |
| Minimum Ground Clearance: | 315mm (including battery) |
| Battery Type: | 90V/48AH – Sony VTC Battery Cell |
| Battery Weight: | 29KG |
| Power Model: | Eco/Rain/Sport + Turbo |
| Front Fork Travel: | 290mm |
| Rear Suspension/Wheel Travel: | 115/290mm |
| Maximum Output Power: | 22.5KW |
| Maximum Torque of Driving Wheel: | 520N.m |
| ABS+ASR+BERS: | ASR+BERS |
| CRATE DATA | |
| WARRANTY | |
| VEHICLE | ||
| Chassis Material: |
|
|
| Chassis Process Method: | TBA | |
| Chassis Weight: | TBA | |
| Chassis Surface & Color Processing: | TBA | |
| LED Headlight: | TBA | |
| Wheel Type & Size: |
TBA |
|
| Tire Size (MX Version): |
Fr.: 80/100-21；Rr.:100/90-18″ |
|
| Tire Brand: |
TBA |
|
| Top Speed Sport Mode / Turbo Mode: |
100km/h (96V) / 110km/h (96V) |
|
| Cruising Range Per Charge: |
≥105km (@50km/h） |
|
| N.W. | TBA | |
| Vehicle Dimension: | TBA | |
| Seat Height: | 940mm | |
| Wheel Base: | 1430mm | |
| Handlebar Width: |
TBA |
|
| Available Colors: | Yellow/Black | |
| Curb Weight: | 95KG (without battery) | |
| Power System: | BLDC MOTOR + FOC sine wave controller | |
| Rim Type: | Front – 21 x 1.60
Rear – 18 x 2.15 19 x 2.15 (Optional) |
|
| Tyre Type: | Front – 80/110 – 21
Rear – 100/90 – 18 100/90 – 19 (Optional) |
|
| Front Suspension System: | FASTace 47mm Inverted Fork | |
| Rear Suspension System: | FASTace Air Absorber | |
| Front Brake: | Dual-piston, 270mm Rotor | |
| Rear Brake: | Dual-piston, 240mm Rotor | |
| Charging Time: | 3H | |
| Frame Type: | Aluminum Alloy Forged Frame | |
| GPS | APP Link | |
